| 모델 번호.: | JP-1936st | 빈도: | 40KHz/28KHz |
|---|---|---|---|
| 힘: | 0-46.8kW | 난방력: | 66kW |
| 순 중량: | 4000kg | 총 체중: | 4300kg |
| 용량: | 7280L / 2000 갤런 | 탱크 크기: | 3.5*1.6*1.3m |
| 단위 크기: | 390*200*200cm | 패키지 크기: | 400*210*210cm |
| 재료: | 스테인레스 스틸 SUS304 | 초음파 전력: | 46800W |
| 온도 셋팅: | 실온 ~ 95 ° C 조정 가능 | 바구니로드: | 2000kg |
| 전원 공급 장치: | 380V 3 단계; 220V 3 단계; 415V; 600V | ||
| 강조하다: | industrial ultrasonic cleaner 7280L capacity,40kHz ultrasonic cleaner industrial,28kHz frequency ultrasonic cleaner |
||
| Item | Parameter | Details |
|---|---|---|
| 1 | Model | JP-1923ST |
| 2 | Function | Ultrasonic cleaning |
| Ultrasonic Frequency | 28/40kHz (customizable) | |
| Tank Material | SUS 304 (SUS 316 customizable) | |
| Thickness of tank | 3mm | |
| Inner tank dimension | 3500×1600×1300mm | |
| Tank Capacity | 7280L | |
| Transducer | 936pcs | |
| Ultrasonic Power | 46800W | |
| Heating Power | 66000W | |
| Time setting | 0-99 hours | |
| Temperature setting | Room temperature to 95°C adjustable | |
| 3 | Packing | Wooden case (No logs, fumigation-free) |
| 4 | Power supply | 380V 3 phase; 220V 3 phase; 415V; 600V |
| 5 | Warranty | 1 year warranty for spare parts, lifetime technical support |
| 6 | Certificate | CE, RoHS, FCC, REACH |
| 7 | Lead time | 20-30 working days after deposit |
